» Flammability: Oxygen Index ≥30;
» Heat-resisting: Operating temperature can be as high as 105°C;
» Low temperature withstand: No cracking down to -55°C;
» Safety: Shorten phase spacing & ground clearance for power distribution system under 1KV;
» Easy installation: Shrunk on bus-bar easily with oven and heat shrink gun.
| Voltage (KV) | Normal insulation distance (mm) | Insulation distance (applied) | |
| Ground (mm) | Phase (mm) | ||
| 10 | 120 | 80 | 70 |
| 22 | 220 | 160 | 120 |
Note: The above data is just for reference. The actual performance can be different according to power distribution systems and environmental situations.
| Model | Bus-bar width (mm) | I.D. after recovery (mm) | Size (mm) |
| MPG10-C-25/10 | 20 ~ 30 | <10 | Φ25x1000 |
| MPG10-C-30/12 | 30 ~ 40 | <12 | Φ30x1000 |
| MPG10-C-40/16 | 40 ~ 50 | <16 | Φ40x1000 |
| MPG10-C-50/20 | 50 ~ 60 | <20 | Φ50x1000 |
| MPG10-C-65/25 | 60 ~ 70 | <25 | Φ65x1000 |
| MPG10-C-75/30 | 80 ~ 90 | <30 | Φ75x1000 |
| MPG10-C-85/35 | 90~100 | <35 | Φ85x1000 |
| MPG10-C-100/40 | 120 | <40 | Φ100x1000 |
| MPG10-C-120/50 | 140 | <50 | Φ120x1000 |
| MPG10-C-150/60 | 180 | <60 | Φ150x1000 |
| MPG10-C-200/60 | 240 | <60 | Φ200x1000 |
Note:
1. Standard colors: RED, YELLOW, GREEN;
2. "C" in Model means color: RD(RED), YW(YELLOW), GN(GREEN);
3. For bus-bar under 1KV, please choose ZRG;
4. Continuous lengths can be custom made.
| Property | Performance | Property | Performance | |
| Hardness | < 80Shore A | Density | 1.15x103Kg/m3 | |
| Water Absorption | < 0.5% | Shrink Temperature | 130±5°C | |
| Radial Shrinking Ratio | > 50% | Longitudinal Change | < 5.0% | |
| Tensile Strength | > 12MPa | Elongation | > 400% | |
| Dielectric Strength | ≥ 25KV/mm | Volume Resistivity | > 1014Ω·cm | |
| Oxygen Index | ≥ 30 | Eccentricity | < 30% | |
