Model
|
Application
|
DH-DF
|
3PE buried pipeline joint: dry film coating
|
DH-PP
|
3PE buried pipeline joint: anti-corrosion coating
|
DH-WF
|
3PE buried pipeline joint: wet film coating
|
DH-DF Dry Film Primer |
|
DH-DF is a dry film primer for use on joint coating of buried pipelines. In comparison to wet film primer, it has much higher lap shear strength. It has 99% solid content and is non-volatile. It adheres strongly to substrates. The cured film will not have any bubbles, voids or cracks. The cured primer layer offers superior corrosion protection against of water and chemicals. It has excellent sealing properties and is highly durable. |
|
DH-PP Primer |
|
DH-PP primer is specially formulated for 3 layer, Polypropylene, buried pipelines. It is the first of its type in China. Compared to other similar products, it has better adhesion, higher bonding strength. In addition to corrosion protection, the coating has very low cathodic disbandment and water permeability. |
|
DH-WF Wet Film Primer |
|
DH-WF is a wet film primer for that used on joint coating of buried pipelines. It has a very high solid content and adheres to most of the common substrates. It is chemical resistant and non-toxic. The cured primer layer offers superior corrosion protection against of water and chemicals. It has excellent sealing properties and is highly durable. Mix the part A and part B in the right proportion and apply to the surface of pipes. |
Property | Performance | Standard | |||
DH-DF | DH-PP | DH-WF | |||
Appearance | Smooth and even | Visual | |||
Thickness µm | > 200 | > 150 | > 150 | GB/T 1764 | |
Solid Content % | 99 | 99 | 99 | GB/T 1725 | |
Fineness µm | < 100 | < 100 | < 100 | GB/T 1724 | |
Density g/cm3 | A | 1.59 | 1.56 | 1.59 | GB/T 13354 |
B | 0.95 | 0.96 | 0.96 | ||
Adhesion (75°C, 48h) | Level 1 | Level 1 | Level 1 | SY/T 0315 | |
Shear Strength (23°C) MPa | 22.6 | 11.5 | 13.2 | GB/T 7124 | |
Cathodic Disbonding mm | 65°C, 48h | 3.6 | 4.5 | 4.4 | GB/T 23257 |
65°C, 30d | 12.4 | 11.5 | 12.8 |
